ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm

  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
  • ISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm
Place of Origin CHINA
Brand Name TISCO
Certification ISO 9001 BV SGS
Model Number DN20、DN25、DN32、DN40、DN50
Minimum Order Quantity 1 TONS
Price Negotiated
Packaging Details Waterproof Wooden Package
Delivery Time Within 7-10 Working Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Stainless Steel Wire Rope Length As Customer’s Demands
Diameter 2mm~40mm , As Customer’s Demands Construction 7x19
Certifications ISO 9001 BV SGS Brand TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO,HXSCO, Chengde,Yongjin,Tsingshan,Shouyang,HW
High Light

BV SGS Stainless Steel Wire Rod

,

Stainless Steel 310S Wire Rod

,

40mm Stainless Steel Wire Rod
Leave a Message
Product Description

Non Magnetic 316 7x19 Stainless Steel Wire Rope



Quick Detail

  1. Model NO.: 316-7x19

  2. Standard: ASTM, AISI, GB, JIS, DIN, EN

  3. Non-Magnetic

  4. Construction: 7X19/6x19+IWRC/6x19S+IWRC/6x19W+IERC

  5. Min Order Qty: 1000 Meters

  6. Delivery Time: 20 Days

  7. Diameter:from 1.5mm to 42mm

  8. Type: Stainless Steel Wire Rope

  9. Grade: AISI316

  10. Surface Treatment: Bright

  11. Stainless Steel: 316 /1.4401/ A4

  12. Delivery Term: EXW,Fob,CNF,CIF

  13. Transport Package: 1000m or 2000m Per Wooden Reel

  14. Other length such as 500m,1500m,2000m,3000m,1000ft,5000 ft are available.

Usage



316 -7x19 Stainless Steel Cable

For nautical, corrosive environments, chemical industry and architecture usage.
Material 304 (1.4301 , A2) and 316 (1.4401, A4) stainless steel both available



7x19 Stainless Steel Cable Specification:



Rope Diameter Nominal Breaking Force Ref.Weight
mm 316 KG/100m
kN
2 2.120 1.640
3 4.780 3.690
4 8.500 6.656
5 13.280 10.250
6 19.120 14.760
7 26.020 20.090
8 34.000 26.240
9 43.000 33.210
10 53.100 41.000
11 64.300 49.610
12 76.500 59.040
13 89.700 69.290
14 104.076 80.360
15 119.475 92.250
16 135.936 104.960
18 172.040 132.840
20 212.400 164.000
21 234.170 180.810
24 305.860 236.160
25 331.880 256.250
26 358.960 277.160
28 416.300 321.440
30 477.900 369.000
32 543.740 419.840
34 613.840 473.960
35 650.480 502.250
36 688.180 531.360
40 849.600 656.000



Prime Quality Steel Wire Rod For Mesh Net

Prime Quality Steel Wire Rod For Mesh Net

Prime Quality Steel Wire Rod For Mesh NetISO 9001 BV SGS Stainless Steel Wire Rod 301 302 310S 201 40mm 3

FAQ



1. How long will it take to execute my order?

Our normal produce time is 7-15 working days.but we have many models in stock.



2. How much will the shipping cost be?

This will depend on the size and weight of your order and the method of shipping.



3. Do you provide samples?

Yes, we can provide samples . We can send the samples by TNT,DHL, FEDEX, EMS, UPS or to your warehouse



4. Do you have products in stock?

There are 600 tons stock for various size .pls kindly inform us what model you need , we will send stock details to you .



5. Can I visit you?

Sure, Pls let us know if you have a plan to visit our company, we will arrange it for you.
